Yehaoxuan Curtain Wall Glass belongs to a high-end window and door system, focusing on "minimalist aesthetics + all-around performance." It integrates the design philosophy of harmony between man and nature, achieving maximized views and architectural aesthetic unity through large-area glass and narrow frames. Its core advantages encompass four dimensions: superior safety protection, high energy efficiency, sound insulation and sealing, and intelligent adaptability. It is suitable for diverse scenarios such as commercial landmarks, high-end buildings, and cultural venues, combining both aesthetics and practicality.
Detailed Introduction
1. Design Concept and Appearance
With "nature integrated into architecture" as its core, Curtain Wall Glass adopts a minimalist frame design and a column-free 90° corner process, reducing the proportion of profiles and achieving a transparency rate of over 95%, seamlessly connecting the outdoor scenery with the indoor space. It offers four profile colors, including fluorocarbon gold and new fluorocarbon gray, adapting to various architectural styles such as modern and light luxury, resulting in a simple and elegant facade that showcases the beauty of architectural order.
2. Core Materials and Processes
- Glass Configuration: Standard configuration is 5+20A+5 double-glazed tempered glass, with optional double-silver/triple-silver Low-E double-glazed (argon-filled) and SGP laminated glass. Argon content reaches 95.5%, maintaining long-term energy-saving performance;
- Profile Structure: 6063-T5 primary aluminum alloy multi-chamber design, with a uniform thickness of 2.0mm, combined with vertical isotherms and five sealing structures, enhancing thermal insulation;
- Safety Technology: The glass undergoes 720℃ homogenization treatment, resulting in a low self-explosion rate of 1/10000. Combined with a closed-loop load-bearing pressure line and ≥100mm metal support strips, it eliminates the risk of falling from high altitudes.
3. Performance Advantages
- Energy Saving: Low-E coating + argon-filled double-glazed design, meeting the Green Building Three-Star standard, providing warmth in winter and coolness in summer, reducing energy consumption;
- Sealing and Protection: The Curtain Wall Glass uses Jiangyin Haida sealing strips and integrated vulcanized welding technology, achieving airtightness level 8 and watertightness level 6, and wind pressure resistance meeting the needs of super high-rise buildings;
- Sound Insulation: 20mm hollow layer + multi-chamber structure, providing sound insulation up to 35dB, effectively blocking external noise;
- Intelligent Adaptation: Can be equipped with an original German control system, supporting automatic window closing with rain and wind sensors, and compatible with various opening methods such as micro-ventilation, sliding, and outward-opening.
4. Applicable Scenarios
Suitable for commercial complexes, office buildings, high-end hotels, museums, transportation hubs, etc., especially ideal for landmark buildings and high-traffic areas with high demands on view, energy saving, and safety.
FAQ
1. What are the safety features of Yehaoxuan Curtain Wall Glass?
Answer: The glass undergoes homogenization treatment to reduce the self-explosion rate, and uses a tempered laminated structure + metal support strips for fixation, complying with national curtain wall safety standards, ensuring no risk of falling in high-rise buildings.
2. How is the energy-saving effect achieved?
Answer: Through the triple energy-saving design of Low-E coating, argon-filled double glazing, and multi-chamber profiles, it can reduce air conditioning energy consumption by more than 30%, meeting environmental standards such as LEED and Green Building Three-Star.
3. Can it be customized according to building needs?
Answer: Supports customization of size, opening method, and profile color, and can be combined with intelligent control systems and special glass (such as colored glaze and dimmable glass) to meet different architectural design needs.
