Conventional Flat Aluminum Single Panel Curtain Walls

Yehaoxuan Conventional Flat Aluminum Single Panel Curtain Walls support customized thickness and can be coated with various finishes such as fluorocarbon, polyester, and wood grain. They possess core characteristics of lightweight, high strength, weather resistance, corrosion resistance, and flexible design.  Dimensions, shapes, and colors can be customized to suit diverse application scenarios such as building facades, lobbies, and canopies. The product is easy to install and has low maintenance costs. All indicators meet building curtain wall energy-saving and safety standards, making it a highly suitable curtain wall solution for commercial buildings, residential developments, and municipal projects.

Detailed Introduction

1. High-Quality Base Material, Robust Performance

The core of the Conventional Flat Aluminum Single Panel Curtain Walls uses 1100/3003/5005 series aluminum alloy plates, with a standard thickness of 2.0-3.0mm, and can be customized to a thickness of up to 4.0mm. The base material has good ductility and high strength, and its wind pressure resistance and impact resistance meet national curtain wall standards. The plates undergo multiple pre-treatments including surface degreasing, pickling, phosphating, and passivation, improving coating adhesion from the source and preventing paint peeling and flaking, making them suitable for complex building environments such as high-rise buildings, coastal areas, and areas with high sun exposure.

2. Multi-Process Spraying, Durable and Weather-Resistant

Multiple spraying processes are available for the surface. Fluorocarbon spraying (PVDF) is the core option, with a fluorine content of ≥70%, providing UV resistance, acid rain resistance, and salt spray resistance, ensuring color retention for over 20 years in outdoor use; polyester spraying (PE) is cost-effective, with rich colors, suitable for indoor and low-sunlight outdoor scenarios; wood grain transfer printing, stone pattern simulation, and frosted brushed finishes are also available to meet the aesthetic needs of different architectural styles. All coatings are formaldehyde-free and comply with green environmental protection standards.

3. Flexible Customization and Strong Adaptability

Supports full customization of size, shape, and openings.  It can be processed into various shapes such as flat panels, folded panels, and curved panels, adapting to various scenarios including building facades, lobby interiors, door canopies, and balcony edging. The panels can be spliced, jointed, or tightly fitted according to design requirements.  Combined with dedicated keel systems and accessories, it perfectly matches the building's facade design, accurately fitting minimalist modern, new Chinese, or light luxury styles.

4. Precision Installation, Safe and Secure

Conventional Flat Aluminum Single Panel Curtain Walls use a dry-hanging installation process with a keel system.  Galvanized steel or aluminum alloy keels are first fixed, and then the aluminum panels are fixed to the keels using hangers. This ensures high installation accuracy, a stable overall structure, and excellent resistance to earthquakes and wind pressure, meeting the safety requirements of high-rise curtain walls. Standardized prefabricated panels and accessories are manufactured in the factory and assembled on-site, resulting in high construction efficiency. The dry-hanging process does not damage the building walls, and later disassembly and replacement of individual panels are more convenient.

5. Lightweight Design, Energy-Saving and Low Maintenance

Conventional Flat Aluminum Single Panel Curtain Walls have low density and light weight, significantly reducing the load-bearing capacity required of the building structure.  The panel surface coating has good heat insulation and reflective properties, reducing heat loss in the building and improving energy efficiency. Daily maintenance is effortless; the smooth surface is easy to clean with water or a neutral detergent.  It does not rust or corrode in outdoor use, eliminating the need for frequent renovation, resulting in low long-term costs. Damaged panels can be replaced individually without affecting the entire curtain wall.

FAQ

1. What are the base material models of conventional aluminum single panels, and what is the range of available thicknesses?

The core materials are 1100/3003/5005 series aluminum alloys, with standard thicknesses of 2.0/2.5/3.0mm.  Thicker panels up to 4.0mm can be customized, with different thicknesses suitable for different building scenarios.

2. What are the surface coating processes, and which scenarios are they suitable for? Fluorocarbon coating (PVDF), polyester coating (PE), wood grain transfer printing, etc.; the fluorocarbon type is suitable for outdoor high-rise curtain walls/coastal environments, the polyester type is suitable for indoor/low-sunlight outdoor environments, and the wood grain type is suitable for interior decoration and distinctive exterior facades.

3. What is the warranty period for fluorocarbon coating, and are there any requirements for the fluorine content?

The fluorocarbon coating has a fluorine content of ≥70%, and provides a color and quality warranty of over 15 years for outdoor use, complying with national curtain wall coating process standards.
